HP Enterprise NVMe Solid State Drive -762770-003 (SanDisk Drive Body) Product Introduction

Overview

        HP 762770-003 is an entry-level enterprise NVMe solid-state drive designed and manufactured by SanDisk (now part of Western Digital) for HPE (Hewlett Packard Enterprise). This model offers a capacity of 1.92TB and uses a standard 2.5-inch U.2 (SFF-8639) interface and NVMe protocol. It is precisely positioned for reading intensive workloads and aims to provide enterprises with the high-speed reading experience and basic data reliability brought by NVMe technology at a highly competitive cost. It is an economical choice for moving towards a full NVMe architecture.

       Core specifications and features

       Project specification description

        Product model HP 762770-003

        Disk manufacturer SanDisk

        Capacity: 92 TB

       Interface | NVMe

       Appearance specification 2.5 inches, U.2 (SFF-8639)

       NAND type 3D TLC NAND

        Durability/endurance up to 1.0 DWPD (daily full disk write count within 5-year warranty) or 3.5 PBW (lifetime write count)

         Highest performance sequential read speed:~3200 MB/s

         Highest sequential write speed:~1100 MB/s

         Random read IOPS: up to 330000 (4K)

         Random write IOPS: up to 30000 (4K)

         Average active power consumption:~8W

         Idle power consumption:~4W

         Reliability index MTBF: 20000 hours

          UBER:<1 error in every 10 ^ 17 bits read

           Main features: Read intensive design: With distinct performance characteristics, it provides extremely high read throughput and moderate write performance, perfectly suited for applications that prioritize reading.

            Basic enterprise level functionality: equipped with basic data protection functions, but usually not equipped with advanced power outage protection (PLP) capacitor arrays. It relies on the power outage protection mechanism of HPE server platform.

            HPE Genuine Guarantee: As an HPE original component, it provides out of the box compatibility, stability, and simplified manageability for server platforms such as HPE ProLiant.

           Cost effectiveness: While providing NVMe high-speed reading advantages, the price is more attractive, making it a powerful tool for optimizing TCO (total cost of ownership).

           Excellent energy efficiency: Low power consumption helps reduce the operating costs and carbon footprint of data centers.

           Applicable scenarios and applications

         This hard drive is an ideal economical choice for reading intensive applications, with typical applications including:

          Web servers and content caching: store and quickly deliver static web pages, images, video streams, and software packages.

          Virtualization host boot volume: serves as the boot driver for hypervisors such as SQLite and Hyper-V, enabling fast boot and efficient management.

           Database read-only replica/report repository: Provides high-speed data access for read-only queries, business intelligence (BI), and data analysis of large databases such as Oracle and SQL Server, reducing the load on the main database.

          Fast access layer for archived data: providing much faster access speed than traditional hard drives (HDDs) for infrequently modified "warm data".

          Enterprise VDI boot image: In virtual desktop infrastructure, quickly read and distribute the same operating system image to multiple users.

Summary of Advantages

          Extremely cost-effective: With a cost close to SATA SSD, it provides NVMe level high-speed read bandwidth, making it an excellent stepping stone for performance upgrades.

           Excellent read performance: The sequential read speed exceeds 3GB/s, which can significantly accelerate the response time of applications that focus on reading.

          Low power consumption and low-carbon: Lower operating power consumption helps build greener and more energy-efficient data centers.

          Seamless HPE Integration: As an original HPE accessory, it can be seamlessly integrated into the HPE server ecosystem, ensuring drive free compatibility and monitoring and management through iLO.

          Sufficient durability: The durability of DWPD is completely sufficient for its target workload (read intensive), ensuring reliable operation during the warranty period.
