R0P97A P13370-001 for HP Primera 7.68T SSD Hard Disk P02434-004 P13373-001

HPE P02434-004 (PM1643) 7.68TB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

          HPE P02434-004 (disk body model PM1643) is a high-performance enterprise NVMe solid-state drive that uses HPE's self-developed enterprise level solution. This hard drive is designed specifically for enterprise critical business systems that require high-performance and large capacity storage, achieving the best balance between performance, capacity, and reliability. It is suitable for application scenarios such as virtualization, databases, and cloud computing.

1. Core features and specifications

         Capacity specification: 7.68TB

         (Adopting intelligent capacity management technology and optimizing OP       configuration to the optimal state)

         Interface protocol: NVMe 1.3 over PCIe 3.0 x4

        Appearance specification: 2.5 inches U.2 (SFF-8639)

        Performance performance:

         Continuous reading speed: up to 3400 MB/s

         Continuous write speed: up to 2400 MB/s

        Random read IOPS: up to 800000 (4K)

         Random write IOPS: up to 130000 (4K)

         Durability index:

         DWPD: 1.2 (5-year warranty period)

         TBW：16.8PB

         MTBF: 2.5 million hours

         Flash Memory Type: 3D eTLC NAND

         (Using enterprise grade enhanced TLC flash memory to provide excellent durability)

2. Advanced features

         Intelligent power management:

         Multi level power consumption state management, power efficiency increased by 25%

          Integrated Advanced Power Failure Protection (PLP) Circuit

         Data Protection:

         End to end data path protection

         Enhanced ECC Error Correction Algorithm

         RAID level data protection function

         Performance optimization:

          Intelligent pre reading and caching algorithm

          QoS Service Quality Control

          Adaptive read-write scheduling

          Security management:

           AES 256 bit hardware encryption

           TCG Enterprise Security Standard

           Instant secure erase function

3. Applicable scenarios

           Enterprise level database:

           Oracle RAC Cluster Database

           SQL Server Large Database

           SAP HANA In Memory Database

           Virtualization platform:

           VMware HANA hyper converged architecture

           Microsoft Hyper-V Virtualization Platform

           Containerized application storage

           Cloud computing:

           Public cloud block storage service

           Private cloud storage resource pool

           Hybrid cloud storage solution

           Big data analysis:

           Real time data analysis platform

           Machine learning training data storage

           Streaming data processing and storage

4. Compatibility information

            Support platform:

             HPE ProLiant DL360/380 Gen10

             HPE ProLiant DL325/385 Gen10+

             HPE Apollo 2000/4000 Series

             HPE Synergy 480/660 Series

             System requirements:

             UEFI 2.5 or higher version

             NVMe 1.3 and above protocol support

             Supports PCIe 3.0 x4 interface

             Management tools:

             HPE iLO 5 Advanced Management Suite

             HPE OneView Unified Management Platform

             HPE InfoSight Predictive Analysis
