Enterprise grade solid state drive HPE 240GB U.2 NVMe PCIe high-speed read suitable for DL380 Gen10 system boot disk

HPE 876596-001 240GB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

          HPE 876596-001 is a high-performance enterprise grade NVMe solid state drive that uses HP's own packaged drive body, optimized for the HPE ProLiant Gen10 server platform. This hard drive is positioned for read intensive application scenarios, providing excellent random read performance and stable low latency performance for enterprise users. It is suitable for use as a system boot disk or cache acceleration disk.

1. Core features and specifications

        Capacity specification: 240GB

        (Adopting enterprise level reserved space design to ensure long-term performance consistency)

         Interface protocol: NVMe 1.3 over PCIe 3.1 x4

         Appearance specification: 2.5 inches U.2 (SFF-8639)

         Performance performance:

         Continuous reading speed: up to 3200 MB/s

         Continuous write speed: up to 1100 MB/s

         Random read IOPS: up to 300000 (4K)

        Random write IOPS: up to 40000 (4K)

        Durability index:

        DWPD: 0.8 (5-year warranty period)

        TBW：350TB

        MTBF: 2 million hours

        Flash Memory Type: 3D TLC NAND

        (Using enterprise grade granules to ensure data reliability)

2. Advanced features

       Intelligent power management:

       Supports multiple power consumption states and can dynamically adjust power  consumption according to workload

        End to end data protection:

        Adopting advanced ECC verification and power-off protection mechanism

       Thermal management function:

       Built in temperature sensor, supporting intelligent temperature control adjustment

        Security features:

        Support secure erasure function, in compliance with enterprise data security standards

3. Applicable scenarios

         Server system boot:

         Provide fast boot support for HPE ProLiant servers

         Read intensive applications:

         Suitable as a database query cache or virtualization platform storage

         Edge computing scenario:

         Provide high-performance storage solutions in space constrained environments

         Cloud infrastructure:

         Virtual machine image storage suitable for cloud platforms

4. Compatibility information

         Support platform:

         HPE ProLiant DL360 Gen10

         HPE ProLiant DL380 Gen10

         HPE ProLiant ML350 Gen10

         System requirements:

         UEFI 2.3.1 or higher version is required

         Supports NVMe 1.3 and above protocols

          Management tools:

         Can be monitored and managed through HPE iLO 5

         Support HPE SSM intelligent storage management
