00DH304 2TB SSD expansion cabinet for IBM FlashSystem AF10 Storwize V5030F 12 bay disk kit 00DH514

Product Description

1.Product Overview

This is an enterprise grade high-capacity hard drive, designed specifically for storage systems such as Storwize V7000 and FlashSystem series. The disk body adopts a 3.5-inch specification, provides 2TB of storage capacity, and runs at 7200 RPM. Its interface is 6Gb/s NL-SAS (Nearline SAS), which perfectly combines the high reliability of SAS interface with the economy close to SATA hard disk, making it an ideal choice for building capacity hierarchy in enterprise storage hierarchy architecture.

Model analysis:

00DH304: This is the FRU (field replaceable unit) number of the hard drive itself, which is the only official code used to identify the spare part.

FC AF10: This code is usually associated with FRU 00DH304, referring to a specific model or configuration batch of the hard drive.

00DH514: This is the FRU number of the drive tray kit or bracket assembly where the hard drive is pre installed. Customers typically receive a complete kit with the hard drive secured in a dedicated rack for easy installation and replacement.

2.Core specifications and parameters

Parameter Project Parameter Details

Product Model (FRU) IBM 00DH304

Driver kit FRU IBM 00DH514

Capacity 2 TB

Interface type 6Gb/s NL-SAS (Near Line SAS)

Physical specification 3.5 inches (standard size outline)

Spindle speed 7200 RPM

The cache size is usually 64MB (please refer to the official data sheet for details)

Average latency~4.17 ms

Mean time between failures 2.0 million hours (2 million hours MTBF)

The workload is suitable for enterprise level 7x24 hour continuous workloads

3.Main features and advantages

Original factory quality and perfect compatibility:

As an original IBM accessory, this hard drive has undergone the strictest testing and validation to ensure 100% hardware compatibility and stability for storage systems such as Storwize V7000. Using original parts can avoid system alarms, performance mismatches, or potential data risks.

Excellent Total Cost of Ownership (TCO):

The essence of NL-SAS technology is the combination of a SATA hard drive body with a SAS interface controller and firmware. This allows it to provide a huge storage capacity (2TB) while maintaining reliability and performance superior to pure SATA hard drives, and at a much lower cost than high-performance 10K/15K SAS hard drives, making it a cost-effective choice for capacity drives.

High reliability:

Specially designed for data center environments that operate 24/7 without interruption. The average time between failures (MTBF) of up to 2 million hours demonstrates its outstanding enterprise level reliability. Adopting SAS interface, supporting dual port access, providing redundant paths for high availability clusters.

Plug and play replacement:

Provided in the form of 00DH514 drive kit, including pre installed hard drive and dedicated bay. This greatly simplifies the replacement process, as technicians can quickly replace faulty disks without any tools, minimizing downtime to the greatest extent possible.

4.Applicable scenarios and system compatibility

Exclusive application: This hard drive is dedicated to the following storage systems:

Storwize V7000

FlashSystem 7200 (as a capacity expansion disk)

FlashSystem 5200 (as a capacity expansion disk)

It may be compatible with other systems (such as some expansion cabinets of the DS8000 series), but the official compatibility list needs to be checked.

Typical workload:

Due to its large capacity and economy, it is often used in these storage systems for:

Data archiving and backup

Cold data storage

Large capacity file sharing

Storage of unstructured data such as videos and images

As a Capacity Tier in Automated Tiered Storage
