108-00260 for NetApp X447A-R6 108-00260 35P2870 35P2871 800G SAS SSD Hard Drive SM1633 800G

NETAPP Enterprise NVMe Solid State Drive - Model 108-00260 (X447A-R6) Product Details

1、 Product Overview

        NETAPP 108-00260 (product model X447A-R6) is an enterprise grade NVMe solid-state drive using Samsung's high-quality flash memory, with a capacity of 800GB. This product is designed specifically for the storage needs of mid to high end enterprises, achieving an excellent balance between performance, durability, and cost-effectiveness, and is suitable for business scenarios with high performance requirements.

2、 Detailed technical specifications

         Parameter Category Detailed Specification Remarks

         Basic Information

         Manufacturer Model X447A-R6 NetApp Custom Model

         NETAPP part number 108-00260 unique identification code

         Samsung Enterprise Flash Granules, a flash memory manufacturer

         Interface Protocol NVMe over PCIe 3.0

        Appearance specification 2.5 inches U.2 enterprise standard appearance

        Capacity information

       Nominal Capacity 800GB Original Capacity

        Available capacity ≈ 730GB considering system redundancy

        performance parameters

        Sequential read speed 3200 MB/s, sustained performance

        Sequential write speed of 1500 MB/s and sustained performance

        4K random read 450000 IOPS queue depth 256

        4K random write 75000 IOPS queue depth 256

        Read/write latency reading<90 μ s, write<20 μ s typical value

        Reliability parameters

        Durability level 3 DWPD daily full disk write count

       Service life 4.3 PBW lifetime write capacity

        Mean time between failures 2000000 hours

        Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. High performance architecture

        Adopting Samsung enterprise grade V-NAND flash memory

        Optimized PCIe 3.0 x4 interface

        High performance flash memory controller

        Support multi queue access

2. Enterprise level reliability

         Power outage protection: Supercapacitors protect data security

         End to end data protection: complete data verification

         Advanced ECC: Powerful Error Correction Capability

         Wear and tear balance: intelligent block management

3. Intelligent management function

         Hot swappable support: online maintenance capability

         S. M.A.R.T.: Health Status Monitoring

         Temperature Management: Dynamic Temperature Control Adjustment

        Firmware Management: Online Upgrade Function

4、 Compatibility information

         Supported NetApp systems:

          AFF A Series Full Flash Array

         FAS8000 series hybrid storage

         Supports ONTAP 9.3 and higher versions

          Physical compatibility:

         Standard 2.5-inch disc position

         Compatible with specific models of disk racks

         Support hot swappable installation

5、 Recommended application scenarios

1. Key applications for enterprises

        Medium sized database system

        virtualization platform

        enterprise application server

2. Performance sensitive applications

        Real time data processing

        Online trading system

        Business Analysis Platform

3. Mixed workloads

       Read write hybrid application

       file share service

       Collaborative platform storage
