Enterprise grade solid state drive 200GB U.2 NVMe PCIe AMD X466B-R6 high-speed read suitable for AMD servers

NETAPP Enterprise NVMe Solid State Drive - Model 108-00323 (X466B-R6) Product Detailed Description

Based on the provided information, here is the translation of the original content:

I. Product Overview

         Please proceed with the translation of the original content

         The NETAPP 108-00323 (Product Model X466B-R6) is an enterprise-grade NVMe solid-state drive with a 200GB capacity, utilizing Toshiba flash technology. Designed specifically for high-performance application scenarios, this product delivers outstanding random read/write performance and low latency despite its relatively small capacity, making it ideal for enterprise storage environments requiring high-speed caching or specific high-performance tiering.

II. Detailed Technical Specifications

        Parameter Category Technical Specifications Remarks

       Basic Information

        Manufacturer Model: X466B-R6

        NETAPP Part Number    108-00323    Unique Identification Code

        Flash Memory Supplier: Toshiba High-Quality Flash Memory Chips

        Interface Protocol NVMe over PCIe

        Physical Specifications 2.5-inch U.2 Enterprise Standard

        Capacity Information

        Nominal Capacity 200GB Original Capacity

        Available capacity 180GB after accounting for system overhead

        Performance Parameters

         Sequential Read Speed  Up to 2,800 MB/s  Sustained Performance

        Sequential Write Speed: Up to 800 MB/s (Sustained Performance)

         4K Random Read

         Maximum 350,000 IOPS

        Queue Depth 256

        4K Random Write

       Up to 50,000 IOPS

       Queue Depth 256

        Read and write latency: Read <100μs, Write <25μs (Typical values)

        Reliability Parameters

3、 Core Technologies and Characteristics

1. High performance design

        Adopting high-quality Toshiba flash memory chips

        Optimized controller architecture

         Low latency feature supporting NVMe protocol

         Optimization for small capacity random read and write operations

2. Enterprise level reliability

         Toshiba Flash Technology: Stable Flash Performance

         Power outage protection: ensuring data security

         Error Correction: Advanced ECC Protection

         Wear and tear balance: extend service life

3. Intelligent management function

        Hot swappable support: online maintenance capability

        Health monitoring: real-time status report

        Temperature management: overheat protection mechanism

        Firmware Management: Online Upgrade Function

4、 Compatibility information

         Supported NetApp systems:

         Early AFF A-series Full Flash Array

         Specific FAS series hybrid storage system

         Support the corresponding version of ONTAP operating system

         Physical compatibility:

        Standard 2.5-inch disc position

        Compatible with specific models of disk racks

        Support hot swappable installation

5、 Recommended application scenarios

1. Cache acceleration layer

          Read cache acceleration

          Write to cache buffer

          Metadata Store

2. System specific partition

         Operating System Partition

         Log file storage

         Temporary data storage

3. Specific workloads

          High frequency small file access

          Metadata intensive applications

         Specific database index storage
