EMC Enterprise NVMe Solid State Drive - Model 118000207-02 Product Details

1、 Product Overview

      EMC 118000207-02 (using Toshiba flash technology) is a high-performance enterprise NVMe solid-state drive with a capacity of 3.84TB. The product is based on Toshiba's advanced 3D TLC NAND flash technology, combined with PCIe interface and NVMe protocol, providing excellent storage performance and reliability for enterprise workloads, and is a key storage component of modern data centers.

2、 Detailed technical specifications

       Detailed specifications of parameter categories

       Basic Information

       EMC part number 118000207-02

       Toshiba 3D TLC NAND Flash Technology

        Interface Protocol NVMe over PCIe 3.0

        Appearance specification 2.5 inches U.2

        Capacity information

       Nominal capacity 3.84TB

        User available capacity ≈ 3.5TB

        performance parameters

        Sequential read speed 3300 MB/s

       Sequential write speed 1900 MB/s

       4K random read 650000 IOPS

      4K random write 160000 IOPS

       Read/write delay: Read<85 μ s, write<16 μ s

       Reliability parameters

       Durability level 3 DWPD

       Service life 21 PBW

       Mean time between failures 2000000 hours

       Annual failure rate 0.44%

       Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. Toshiba Flash Memory Technology Innovation

        Adopting Toshiba BiCS FLASH 3D TLC NAND

       64 layer stacked architecture

       Innovative Memory Hole Process Technology

       High reliability storage unit design

2. Enterprise level reliability

       Power outage protection mechanism: complete data protection circuit

        End to end data protection: full path data integrity verification

       Advanced Error Correction Technology: LDPC Error Correction

        Intelligent Health Management: Real time Flash Health Monitoring

3. Intelligent management function

        Hot swappable support: online maintenance capability

        Health status monitoring: S.M.A.R.T. attribute monitoring

        Temperature Management: Dynamic Temperature Control Adjustment

        Remote management: Standard management interface support

4、 Compatibility information

        Supported Dell EMC Systems:

        Unity series storage array

        PowerEdge series servers

         VxRail hyper fusion system

       PowerMax All Flash Array

       Operating system support:

      VMware HANA 6.7 and above

      Windows Server 2016/2019

     Red Hat Enterprise Linux 7/8

      SUSE Linux Enterprise Server 12/15

5、 Recommended application scenarios

1. Key business of the enterprise

     Large scale database system

     Virtualization platform storage

     Enterprise Application Server

2. Cloud computing environment

      Private cloud storage infrastructure

      Hybrid cloud storage solution

     Cloud native application storage

3. Data analysis

     Business Intelligence Analysis

     Big data processing

     Real time data processing

4. Data Protection

      Backup storage acceleration layer

      Disaster recovery storage

      Data hierarchical storage

6、 Summary of Product Advantages

       performance advantage

       Balanced read and write performance

       Stable low latency

       Good IOPS performance

       Reliability advantage

       Toshiba's high-quality flash memory technology

       Enterprise level durability design

       Comprehensive data protection

        cost advantage

      Optimized total cost of ownership

       High energy efficiency design

       Long term operational economy

7、 Environmental specifications

       Parameter specifications

      Working temperature: 0 ° C to 55 ° C

     Storage temperature -40 ° C to 70 ° C

      Working humidity 8% to 90% non condensing

      Working altitude of 3000 meters

      Typical power consumption 10-12W

     Maximum power consumption 18W

     Anti vibration 5.0 Grms (5-800 Hz)
