Enterprise grade giant PM1723B 15.36TB U.2 NVMe SSD ultra durable 122K TBW database AI storage disk

EMC Enterprise NVMe Solid State Drive - Model 118000674 Product Detailed Description

I. Product Overview

      The EMC 118000674 (Model PM1723B) is an enterprise-grade NVMe SSD with an ultra-high capacity of up to 15.36TB. This product represents the pinnacle of current enterprise storage technology, featuring the latest 3D TLC NAND flash memory and PCIe 4.0 interface, specifically designed for data-intensive workloads. It sets new industry standards in storage density, performance, and reliability.

II. Detailed Technical Specifications

       Parameter Category Technical Specifications

       Basic Information

       EMC Part Number 118000674

       Disk Model: PM1723B

        Interface Protocol: NVMe over PCIe 4.0

       Physical Dimensions: 2.5-inch U.2

       Capacity information

       Nominal Capacity: 15.36TB

       Available capacity ≈14.0TB

       Performance parameters

       Sequential read speed: 7,200 MB/s

       Sequential write speed: 4,500 MB/s

       4K Random Read: 1,600,000 IOPS

       4K Random Write 350,000 IOPS

       Read and Write Latency

       Read <60μs, Write <8μs

       Reliability parameters

       Durability rating: 3 DWPD

       Service life: 84 PBW

        Mean Time Between Failures: 2,500,000 hours

        Annual failure rate: 0.35%

        Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. Innovative Architecture Design

        PCIe 4.0 x4 interface, offering a transmission rate of 16 GT/s

       Supports all advanced features of the NVMe 1.4 standard

       Innovative NAND Flash Packaging Technology

        Intelligent power management, optimizing energy efficiency ratio

2. Enterprise-Level Reliability Engineering

        Multi-layer power failure protection: dual protection with supercapacitor and flash memory backup

        End-to-end data protection: Complete data integrity verification

        Advanced RAID Protection: Chip-level Redundancy Protection

        Smart Error Recovery: Real-Time Error Detection and Repair

3. Advanced Management Features

         Hot-swapping support: Online maintenance and replacement

         Predictive Analysis: Machine Learning-Based Fault Prediction

         Intelligent Temperature Regulation: Multi-zone Temperature Monitoring

         Remote Management: Full NVMe-MI Management Support

IV. Compatibility Information

         Supported Dell EMC Systems:

         PowerMax Series: PowerMax 2500/8500

        Unity XT Series: 880F/680F

        PowerEdge MX Series

        VxRail Hyper-Converged System

        Software Environment Support:

        VMware vSphere 7.0 or later

        Windows Server 2022

        Red Hat Enterprise Linux 8/9

        SUSE Linux Enterprise Server 15 SP3

V. Recommended Application Scenarios

1. Ultra-large-scale data centers

        Converged infrastructure

        Software-defined Storage Platform

        Cloud service provider infrastructure

2. Key Business Operations

         Large data warehouse

         Enterprise Resource Planning System

          Key business database

3. High-performance computing

          Artificial Intelligence Training Platform

          Machine learning workloads

         Scientific Computing Simulation

4. Data-intensive applications

         4K/8K video processing

         Genomic sequencing analysis

          Financial Risk Modeling

VI. Summary of Product Advantages

         Capacity advantage

         Industry-leading storage density

        Optimized spatial efficiency

        Significantly reduce total cost of ownership

         Performance advantage

         Excellent Throughput Performance

         Ultra-low latency response

         Stable service quality guarantee

         Reliability advantage

         Enterprise-grade durability design

         Multi-layer data protection mechanism

         Predictive maintenance capability

VII. Environmental Specifications

         Parameter  Specification

         Operating temperature: 0°C to 55°C

         Storage temperature: -40°C to 70°C

         Operating Humidity: 8% to 90% Non-condensing

         Working altitude: 3,050 meters

         Typical power consumption: 14-16W

         Maximum power consumption: 25W

         Vibration resistance: 5.0 Grms (5-800 Hz)
