005053079 MZ-WLL3T8C 118000741 MZWLL3T8HAJQ-000C9 PM1723b 3.84TB MVMe SSD in Stock for EMC

NETAPP Enterprise NVMe Solid State Drive - Model 118000741 (005053079) Product Details

1、 Product Overview

        NETAPP 118000741 (disk model PM1723B) is a high-performance enterprise grade NVMe solid state drive with a capacity of 3.84TB. The product uses advanced 3D TLC NAND flash technology and is designed specifically for modern enterprise workloads, achieving excellent balance in performance, capacity, and reliability, making it suitable      for a variety of data intensive application scenarios.

2、 Detailed technical specifications

        Parameter Category Detailed Specification Remarks

Basic Information

        NETAPP part number 118000741 main identification code

       Auxiliary part number 005053079 spare identification code

       Disk model PM1723B physical disk identification

      NVMe over PCIe 4.0 interface protocol latest interface standard

      Appearance specification 2.5 inches U.2 (SFF-8639) enterprise standard

      Capacity information

       Nominal capacity 3.84TB original capacity

        Available capacity ≈ 3.5TB considering RAID and system overhead

         performance parameters

         Sequential read speed 6500 MB/s PCIe 4.0 performance

         Sequential write speed 3800 MB/s Continuous write performance

        4K random read 900000 IOPS high queue depth

        4K Random Write 250000 IOPS Random Write Performance

        Read/write latency reading<70 μ s, write<12 μ s low latency performance

       Reliability parameters

        Durability level 5 DWPD daily full disk write count

        Service life 35 PBW lifetime write capacity

       Mean time between failures 2500000 hours

3、 Core Technologies and Characteristics

1. High performance architecture

       PCIe 4.0 x4 interface, doubled bandwidth

       Optimized NVMe protocol stack

       Support multi namespace isolation

        dynamic power management

2. Enterprise level reliability

        Advanced power-off protection: multi-layer data protection mechanism

        End to end data integrity: complete CRC check

        Intelligent Error Recovery: Automatic Error Detection and Repair

        Wear Balance Algorithm: Extending Flash Memory Life

3. Intelligent management function

         Hot swappable support: online maintenance capability

        S. M.A.R.T. Enhanced Monitoring: Predictive Fault Analysis

        Temperature adaptive adjustment: intelligent temperature control management

        Remote management support: NVMe MI standard management interface

4、 Compatibility information

        Supported NetApp systems:

        AFF A-series Full Flash Array: A250, A400, A800

       FAS9500 series hybrid storage system

       Supports ONTAP 9.8 and higher versions

        Physical compatibility:

       Standard 2.5-inch disc position

        DS224C, DS460C disk rack

         Support hot swappable installation

5、 Recommended application scenarios

1. High performance computing

        Real time data analysis

        AI/machine learning workloads

        Scientific computing simulation

2. Key applications for enterprises

        Large scale database systems (Oracle, SQL Server)

        ERP system storage

       Virtualization infrastructure

3. Cloud service environment

       Private cloud storage platform

        Hybrid cloud storage solution

       Container persistent storage
