Enterprise grade solid state drive PM1723B 7.68T U.2 NVMe PCIe 3.0 ultra large capacity data warehouse monitoring storage disk

EMC Enterprise NVMe Solid State Drive - Model 118033281 Product Detailed Description

1. Product Overview

       The EMC 118033281 (model PM1723B) is a high-performance enterprise-grade NVMe SSD with a capacity of up to 7.68TB. This product utilizes the latest 3D TLC NAND flash technology and PCIe 4.0 interface, specifically designed for high-demand workloads in modern data centers, achieving a perfect balance between large capacity, high performance, and exceptional reliability.

II. Detailed Technical Specifications

      Parameter Category  Detailed Specifications  Notes

      Basic Information

       EMC Part Number 118033281 Primary Identification Code

       Disk Model: PM1723B

       Physical Disk Identifier

       Interface Protocol: NVMe over PCIe 4.0 (Latest Interface Standard)

       Form Factor: 2.5-inch U.2 (SFF-8639)

       Enterprise Standard

       Capacity information

       Nominal Capacity 7.68TB  Original Capacity

       Available capacity ≈7.0TB after accounting for system redundancy

       Performance parameters

       Sequential read speed: 7,000 MB/s PCIe 4.0 performance

       Sequential Write Speed: 4,200 MB/s

       Sustained Write Performance

       4K Random Read 1,400,000 IOPS High Queue Depth

       4K Random Write  300,000 IOPS  Random Write Performance

       Read and Write Latency

       Read <65μs, Write <10μs

       Ultra-Low Latency

       Reliability parameters

       Durability Rating: 3 DWPD (Drive Writes Per Day)

       Service Life: 42 PBW (Total Data Written)

III. Core Technologies and Features

1. High-performance Architecture Design

     PCIe 4.0 x4 interface delivers double the bandwidth of PCIe 3.0

      Supports NVMe 1.4 standard features

      Multi-namespace Management

       Advanced Queue Management Mechanism

2. Enterprise-level reliability assurance

       Full-path power-off protection: Supercapacitor ensures data safety

        End-to-end Data Protection: Complete Data Integrity from Host to Flash

         Advanced ECC Error Correction: LDPC Error Correction Technology

         Intelligent Wear Leveling: Dynamic Wear Management Algorithm

3. Intelligent Management Function

       Hot-swap support: online maintenance and replacement

        S.M.A.R.T. Enhanced Monitoring: Predictive Failure Analysis

        Temperature Intelligent Regulation: Dynamic Thermal Throttling

        Remote Management Interface: Supports the NVMe-MI standard

IV. Compatibility Information

         Supported Dell EMC Systems:

         PowerMax Series: PowerMax 2000, 8000

         Unity Series: Unity XT

         PowerEdge MX series

          Support for VMware vSAN Ready Nodes

         Operating System Support:

         Windows Server 2019/2022

        Red Hat Enterprise Linux 7/8

        VMware ESXi 7.0 or higher

        SUSE Linux Enterprise Server

V. Recommended Application Scenarios

1. Key Business of the Enterprise

        Large databases (Oracle Exadata, SAP HANA)

        Enterprise Resource Planning System

       Critical Business Application Storage

2. Cloud Data Center

         Software-Defined Storage Solution

         Converged infrastructure

        Cloud-native application storage

3. High-Performance Computing

         Artificial Intelligence and Machine Learning

        Real-time data analysis

        High-performance computing cluster

4. Virtualization Environment

        Large-scale VDI deployment

       Server virtualization

       Container persistent storage
