Hitachi 3.84T NVMe U.2 Solid State Drive 3.84TB Enterprise SSD 118000588-03 Server Hard Drive

EMC Enterprise NVMe Solid State Drive - Model 118000588-03 Product Details

1、 Product Overview

        EMC 118000588-03 (using Hitachi flash technology) is a high-performance enterprise grade NVMe solid state drive with a capacity of 3.84TB. The product is based on Hitachi's high-quality flash technology and is designed specifically for the high demand workloads of modern data centers. It achieves outstanding balance in performance, capacity, and reliability, making it an ideal storage solution for critical business applications in enterprises.

2、 Detailed technical specifications

       Detailed specifications of parameter categories

       Basic Information

       EMC part number 118000588-03

       Hitachi 3D TLC NAND Flash Technology

       Interface Protocol NVMe over PCIe 4.0

       Appearance specification 2.5 inches U.2

       Capacity information

        Nominal capacity 3.84TB

        Available capacity ≈ 3.5TB

        performance parameters

        Sequential read speed 6800 MB/s

        Sequential write speed 3900 MB/s

        4K random read 1100000 IOPS

       4K random write 260000 IOPS

       Read/write delay: Read<75 μ s, write<15 μ s

        Reliability parameters

        Durability level 5 DWPD

        Service life 35 PBW

        Mean time between failures 2500000 hours

        Annual failure rate 0.44%

        Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. Hitachi Flash Memory Technology Innovation

        Adopting Hitachi's advanced 3D TLC NAND technology

        PCIe 4.0 x4 interface, providing high bandwidth

        Optimized flash controller architecture

        Supports NVMe 1.4 standard features

2. Enterprise level reliability engineering

         Multi layer power-off protection: a complete capacitor backup system

         End to end data integrity: full path data protection

         Advanced Error Correction: Powerful LDPC Error Correction Capability

         Intelligent Wear Management: Dynamic Balance Algorithm

3. Intelligent management function

        Hot swappable support: online maintenance capability

        Predictive Health Monitoring: Enhanced S.M.A.R.T

        Intelligent temperature control: multi zone temperature monitoring

        Remote management support: NVMe MI standard interface

4、 Compatibility information

        Supported Dell EMC Systems:

        PowerMax series: 2000/8000/2500/8500

         Unity XT series: 380F/480F/680F/880F

         PowerEdge MX series servers

          VxRail hyper fusion system

          Software environment support:

          VMware HANA 7.0 and above

          Windows Server 2019/2022

          Red Hat Enterprise Linux 8/9

         SUSE Linux Enterprise Server 15

5、 Recommended application scenarios

1. Key business of the enterprise

        Large scale database systems (Oracle, SQL Server)

       SAP HANA In Memory Computing Platform

       Enterprise Resource Planning System

2. Virtualization environment

       Large scale virtualization deployment

       Virtual Desktop Infrastructure (VDI)

       Containerized platform storage

3. Data analysis platform

        Real time data processing

        Business Intelligence Analysis

        Artificial Intelligence/Machine Learning

4. Cloud service infrastructure

        Private cloud storage platform

        Hybrid cloud storage solution

        Cloud native application storage

6、 Summary of Product Advantages

         performance advantage

         Excellent read and write throughput

         Stable low latency performance

         Excellent IOPS performance

         Capacity advantage

         High storage density design

         Optimized capacity efficiency

         Good scalability

         Reliability advantage

         Hitachi's high-quality flash memory technology

         Enterprise level durability design

         A comprehensive data protection mechanism

7、 Environmental specifications

         Parameter specifications

         Working temperature: 0 ° C to 55 ° C

         Storage temperature -40 ° C to 70 ° C

         Working humidity 8% to 90% non condensing

         Working altitude 3050 meters

         Typical power consumption 11-13W

         Maximum power consumption 20W

         Anti vibration 5.0 Grms (5-800 Hz)
