1. Product Overview

        The EMC 118000747-01 is a high-performance enterprise-grade NVMe solid-state drive utilizing Intel 3D NAND flash technology, with a capacity of 3.84TB. Designed for demanding workloads in modern data centers, this product is based on the PCIe 4.0 interface and NVMe protocol, achieving an exceptional balance of performance, capacity, reliability, and energy efficiency.

II. Detailed Technical Specifications

        Parameter Category Detail Specifications

        Basic Information

        EMC Part Number 118000747-01

        Flash Technology

        Intel 3D TLC NAND

        Interface Protocol: NVMe 1.4 over PCIe 4.0

        Form Factor: 2.5-inch U.2 (15mm thickness)

        Capacity Information

        Nominal Capacity: 3.84TB

        Available user capacity  3.5TB (including system reserved space)

        Performance parameters

        Sequential read speed: 7,000 MB/s

        Sequential Write Speed 4,200 MB/s

        4K Random Read: 1,400,000 IOPS

       4K Random Write 300,000 IOPS

       Read/Write Latency: Read <70μs, Write <10μs

       Reliability parameters

       Durability Level 3 DWPD

      Service Life: 21 PBW (Total Data Written)

      Mean Time Between Failures (MTBF) 2,500,000 hours

     Unrecoverable error rate <1e-17

     Warranty Policy: 5Year Limited Warranty

III. Core Technologies and Features

1. Intel 3D NAND Technology

      Equipped with 144-layer 3D TLC NAND flash memory

      Innovative Floating Gate Memory Cell

      High-density storage architecture

      Optimized charge retention characteristics

2. Enterprise-level reliability

       Full Path Power Failure Protection: Onboard Super Capacitor Array

      End-to-end data protection: Full data path validation

      Advanced Error Correction Technology: Third-Generation LDPC Error Correction

      Smart Wear Leveling: Dynamic Wear Leveling Algorithm

3. Smart Management Function

      Hot-swap support: Compliant with NVMe hot-swap standards

      Health Status Monitoring: Telemetry 2.0 Remote Sensing Technology

       Temperature Management: Multi-zone Temperature Monitoring and Regulation

       Remote Management: NVMe-MI 1.1 Management Interface

IV. Compatibility Information

       Supported Dell EMC Systems:

       PowerMax 2500/8500 All-Flash Array

       PowerEdge MX Series Modular Servers

      Unity XT 380/480/680/880 Hybrid Storage

      VxRail P Series/V Series Hyper-Converged Systems

      Operating System Support:

       VMware vSphere 7.0 U3 and above

       Windows Server 2022

      Red Hat Enterprise Linux 8.4 or higher

     SUSE Linux Enterprise Server 15 SP3

V. Recommended Application Scenarios

1. Key Business of the Enterprise

      Large Database Systems (Oracle Exadata)

     SAP HANA In-Memory Computing Platform

      Enterprise Resource Planning System

2. Virtualization and Cloud Computing

       Enterprise-grade virtualization platform

       Converged infrastructure

      Hybrid cloud storage solution

3. Data Analysis and AI

       Real-time Data Analytics Platform

       Artificial Intelligence/Machine Learning Training

       Big Data Processing Cluster

4. High-performance computing

        Scientific Research Computation

         Financial Risk Modeling

         Media Content Production
