EM-C Powerstore Hard Driver NVME SSD 1.92TB 005053077/MZ-WLL1T9C/118000740

EMC Enterprise NVMe Solid State Drive - Model 118000740 Product Details

1、 Product Overview

        EMC 118000740 (disk body model PM1723B) is a high-performance enterprise grade NVMe solid state drive with a capacity of 1.92TB. The product uses advanced 3D TLC  NAND flash technology, based on PCIe 4.0 interface and NVMe protocol, designed specifically for high demand workloads in modern data centers, achieving a perfect balance between performance, reliability, and cost-effectiveness.

2、 Detailed technical specifications

         Detailed specifications of parameter categories

         Basic Information

         EMC part number 118000740

         Disk model PM1723B

         Flash technology 3D TLC NAND

         Interface protocol NVMe 1.4 over PCIe 4.0

         Appearance specification 2.5 inches U.2 (7mm thickness)

         Capacity information

         Nominal capacity 1.92TB

         User available capacity ≈ 1.75TB

          performance parameters

         Sequential read speed 6800 MB/s

        Sequential write speed 3500 MB/s

         4K random read 950000 IOPS

         4K random write 220000 IOPS

         Read/write delay: Read<70 μ s, write<12 μ s

         Reliability parameters

         Durability level 3 DWPD

         Service life 10.5 PBW

         Mean time between failures 2500000 hours

        Annual failure rate 0.35%

        Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. High performance architecture

        PCIe 4.0 x4 interface, providing a transfer rate of 16 GT/s

       Support multiple namespaces and SRIOVs

       Optimized parallel processing architecture

       Low power and high-performance controller

2. Enterprise level reliability

       Full path power-off protection: enhanced supercapacitor

       End to end data protection: complete data integrity verification

       Advanced LDPC Error Correction: Fourth Generation LDPC Error Correction

        Intelligent Health Monitoring: Real time Flash Health Management

3. Intelligent management function

        Hot swappable support: Compliant with NVMe hot swappable standards

        Telemetry: Real time performance monitoring

        Intelligent temperature control: Multi zone temperature sensor

        Remote management: NVMe MI 1.1 management interface

4、 Compatibility information

        Supported Dell EMC Systems:

         PowerMax 2500/8500 Full Flash Array

         Unity XT 380F/480F/680F/880F

          PowerEdge MX series servers

         VxRail P Series/V Series

         Software environment support:

         VMware HANA 7.0 U2 and above

         Windows Server 2022

         Red Hat Enterprise Linux 8.4 and above

         SUSE Linux Enterprise Server 15 SP3

5、 Recommended application scenarios

1. Key business of the enterprise

         Medium sized database systems (Oracle, MySQL)

         Virtualization platform storage

          Enterprise Application Server

2. Cloud computing environment

         Private cloud storage infrastructure

         Hybrid cloud storage solution

         Cloud native application storage

3. Data analysis

        Real time data processing

        Business Intelligence Analysis

        Machine learning inference workload

4. Virtualization deployment

        Virtual Desktop Infrastructure (VDI)

         Server virtualization

         Container platform storage
