005053704 3.84TB NVMe 2.5" SSD Server Series Solid State Drives Disk 118000839 MZWLJ3T8HBLS-00AC9

EMC Enterprise NVMe Solid State Drive - Model 118000839 Product Detailed Description

1. Product Overview

        The EMC 118000839 (Part Number: 005053704) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. This product utilizes the latest 3D TLC NAND flash technology, based on the PCIe 4.0 interface and NVMe protocol, specifically designed for demanding workloads in modern data centers, achieving an exceptional balance of performance, reliability, and energy efficiency.

II. Detailed Technical Specifications

       Parameter Category  Detailed Specifications

       Basic Information

       EMC Part Number 118000839

       Replacement Part Number 005053704

        Flash Memory Technology: 3D TLC NAND

        Interface Protocol: NVMe 1.4 over PCIe 4.0

        Form factor: 2.5-inch U.2

        Capacity information

        Nominal Capacity: 1.92TB

       User available capacity ≈1.75TB

       Performance Parameters

      Sequential read speed: 6,900 MB/s

       Sequential write speed: 3,600 MB/s

       4K Random Read  980,000 IOPS

       4K Random Write 230,000 IOPS

        Read/Write Latency: Read <68μs, Write <11μs

        Reliability parameters

        Durability Level 3 DWPD

        Service life: 10.5 PBW

        Mean Time Between Failures: 2,500,000 hours

        Annual failure rate: 0.35%

        Warranty Policy: 5-Year Limited Warranty

3. Core Technologies and Features

1. High-performance architecture

        PCIe 4.0 x4 interface, offering a data transfer rate of 16 GT/s

        Supports multiple namespaces and SR-IOV

        Optimized parallel processing architecture

        Low-power high-performance controller

2. Enterprise-level reliability

        Full Path Power Failure Protection: Enhanced Super Capacitor

        End-to-end data protection: comprehensive data integrity verification

         Advanced LDPC Error Correction: Fourth-Generation LDPC Error Correction

       Smart Health Monitoring: Real-time Flash Memory Health Management

3. Smart Management Function

        Hot-swap support: Compliant with NVMe hot-swap standards

        Telemetry: Real-time Performance Monitoring

        Smart Temperature Regulation: Multi-Zone Temperature Sensors

        Remote Management: NVMe-MI 1.1 Management Interface

IV. Compatibility Information

        Supported Dell EMC Systems:

        PowerMax 2500/8500 All-Flash Array

        Unity XT 380F/480F/680F/880F

         PowerEdge MX series servers

         VxRail P Series/V Series

        Software Environment Support:

        VMware vSphere 7.0 U3 and above

         Windows Server 2022

         Red Hat Enterprise Linux 8.5 or later

         SUSE Linux Enterprise Server 15 SP3

V. Recommended Application Scenarios

1. Key Business of Enterprises

         Medium-sized database system

        Virtualization platform storage

        Enterprise application server

2. Cloud computing environment

       Private cloud storage infrastructure

        Hybrid cloud storage solution

       Cloud-native application storage

3. Data Analysis

        Real-time data processing

         Business Intelligence Analysis

        Machine learning inference workloads

4. Virtualization Deployment

        Virtual Desktop Infrastructure (VDI)

        Server virtualization

        Container platform storage
