For DELL EMC POWERSTORE SSD 1.92TB NVME 2.5` 005052920 005053702 005053076 005053077 005053703 118000838 005052919 005052920 SSD

EMC Enterprise NVMe Solid State Drive - Model 118000839 Product Detailed Description

1. Product Overview

       The EMC 118000839 (Part Number: 005053704) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. This product utilizes the latest 3D TLC NAND flash technology, based on the PCIe 4.0 interface and NVMe protocol, specifically designed for demanding workloads in modern data centers, achieving an exceptional balance of performance, reliability, and energy efficiency.

II. Detailed Technical Specifications

       Parameter Category  Detailed Specifications

       Basic Information

       EMC Part Number 118000839

       Replacement Part Number 005053704

       Flash Memory Technology: 3D TLC NAND

       Interface Protocol: NVMe 1.4 over PCIe 4.0

        Form factor: 2.5-inch U.2

       Capacity information

       Nominal Capacity: 1.92TB

       User available capacity ≈1.75TB

       Performance Parameters

       Sequential read speed: 6,900 MB/s

       Sequential write speed: 3,600 MB/s

       4K Random Read  980,000 IOPS

      4K Random Write 230,000 IOPS

      Read/Write Latency: Read <68μs, Write <11μs

      Reliability parameters

      Durability Level 3 DWPD

      Service life: 10.5 PBW

      Mean Time Between Failures: 2,500,000 hours

       Annual failure rate: 0.35%

      Warranty Policy: 5-Year Limited Warranty

3. Core Technologies and Features

1. High-performance architecture

       PCIe 4.0 x4 interface, offering a data transfer rate of 16 GT/s

        Supports multiple namespaces and SR-IOV

       Optimized parallel processing architecture

        Low-power high-performance controller

2. Enterprise-level reliability

        Full Path Power Failure Protection: Enhanced Super Capacitor

        End-to-end data protection: comprehensive data integrity verification

        Advanced LDPC Error Correction: Fourth-Generation LDPC Error Correction

        Smart Health Monitoring: Real-time Flash Memory Health Management

3. Smart Management Function

        Hot-swap support: Compliant with NVMe hot-swap standards

         Telemetry: Real-time Performance Monitoring

         Smart Temperature Regulation: Multi-Zone Temperature Sensors

         Remote Management: NVMe-MI 1.1 Management Interface

IV. Compatibility Information

         Supported Dell EMC Systems:

         PowerMax 2500/8500 All-Flash Array

         Unity XT 380F/480F/680F/880F

        PowerEdge MX series servers

         VxRail P Series/V Series

        Software Environment Support:

         VMware vSphere 7.0 U3 and above

         Windows Server 2022

         Red Hat Enterprise Linux 8.5 or later

        SUSE Linux Enterprise Server 15 SP3

V. Recommended Application Scenarios

1. Key Business of Enterprises

        Medium-sized database system

        Virtualization platform storage

        Enterprise application server

2. Cloud computing environment

        Private cloud storage infrastructure

        Hybrid cloud storage solution

        Cloud-native application storage

3. Data Analysis

       Real-time data processing

        Business Intelligence Analysis

        Machine learning inference workloads

4. Virtualization Deployment

        Virtual Desktop Infrastructure (VDI)

        Server virtualization

        Container platform storage
