005053704 3.84TB NVMe 2.5" SSD Server Series Solid State Drives Disk 118000839 MZWLJ3T8HBLS-00AC9

EMC Enterprise NVMe Solid State Drive - Model 118000838 Product Detailed Description

1. Product Overview

         The EMC 118000838 (model number PM1733) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. This product utilizes advanced 3D TLC NAND flash technology, featuring a PCIe 4.0 interface and NVMe protocol, delivering exceptional performance and reliability for enterprise workloads. It serves as an ideal storage solution for building modern data centers.

II. Detailed Technical Specifications

        Parameter Category Detail Specifications

         Basic Information

         EMC Part Number 118000838

         Disk Model: PM1733

         Flash memory type: 3D TLC NAND

         Interface Protocol: NVMe over PCIe 4.0

         Form factor: 2.5-inch U.2

         Capacity information

         Nominal Capacity: 1.92TB

         Available user capacity ≈1.75TB

         Performance parameters

         Sequential read speed: 6,500 MB/s

         Sequential write speed: 3,200 MB/s

         4K Random Read 900,000 IOPS

        4K Random Write 200,000 IOPS

        Read and Write Latency: Read <75μs, Write <15μs

        Reliability parameters

        Durability Rating: 5 DWPD

        Service life: 17.5 PBW

        Mean Time Between Failures: 2,500,000 hours

        Annual failure rate: 0.44%

        Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. High-performance architecture design

        PCIe 4.0 x4 interface, delivering high bandwidth

        Supports NVMe 1.4 standard features

        Optimized Flash Controller

        Low-latency architecture design

2. Enterprise-level Reliability

        Power Failure Protection Mechanism: Super Capacitor Data Protection

        End-to-end data protection: comprehensive data integrity verification

        Advanced Error Correction: LDPC Error Correction Technology

        Intelligent Wear Leveling: Dynamic Block Management

3. Smart Management Function

        Hot-swap support: Online maintenance capability

        Health Status Monitoring: Enhanced S.M.A.R.T

        Temperature Management: Dynamic Temperature Control Adjustment

        Remote Management: NVMe-MI Management Interface

IV. Compatibility Information

         Supported Dell EMC Systems:

        PowerMax 2500/8500 Series

         Unity XT 380F/480F/680F/880F

         PowerEdge MX Series Servers

         VxRail P Series/V Series

          Operating System Support:

         VMware vSphere 7.0 or later

         Windows Server 2019/2022

         Red Hat Enterprise Linux 8/9

        SUSE Linux Enterprise Server 15

V. Recommended Application Scenarios

1. Key Enterprise Applications

         Medium-sized database system

         Virtualization platform storage

          Enterprise application server

2. Cloud Computing Environment

         Private cloud storage infrastructure

         Hybrid Cloud Storage Solution

        Cloud-native application storage

3. Data Analysis

        Real-time data processing

        Business Intelligence Analytics

        Machine learning workloads

4. Virtualization Deployment

        Virtual Desktop Infrastructure (VDI)

         Server virtualization

         Container platform storage
