Enterprise grade solid state drive 7.68TB U.2 NVMe SSD 118000748-01 ultra large capacity data center level storage solution

EMC Enterprise NVMe Solid State Drive - Model 118000748-01 Product Details

1、 Product Overview

        EMC 118000748-01 is a product that uses Intel technology ® The latest 3D NAND flash technology for ultra large capacity enterprise NVMe solid-state drives, with a capacity of up to 7.68TB. This product is based on PCIe 4.0 interface and NVMe protocol, designed specifically for the extreme performance requirements of modern data centers, setting a new industry benchmark in storage density, performance, and reliability.

2、 Detailed technical specifications

         Detailed specifications of parameter categories

         Basic Information

         EMC part number 118000748-01

        Flash technology from Intel ®  144 layer 3D TLC NAND

         Interface protocol NVMe 1.4 over PCIe 4.0

        Appearance specification 2.5 inches U.2 (15mm thickness)

        Capacity information

        Nominal capacity 7.68TB

        User available capacity ≈ 7.0TB

        performance parameters

         Sequential read speed 7200 MB/s

         Sequential write speed 4500 MB/s

         4K random read 1600000 IOPS

         4K random write 350000 IOPS

         Read/write delay: Read<65 μ s, write<8 μ s

         Reliability parameters

         Durability level 3 DWPD

         Service life 84 PBW

         Mean time between failures 2500000 hours

         Unrepairable error rate<1e-17

        Warranty Policy 5-year Limited Warranty

3、 Core Technologies and Characteristics

1. Intel ® Innovative Flash Memory Technology

         Adopting 144 layer 3D TLC NAND

        Innovative floating gate technology

        High density storage unit design

        Optimized charge retention capability

2. Enterprise level reliability assurance

        Full path power-off protection: enhanced supercapacitor array

        End to end data protection: complete data path protection

        Advanced LDPC Error Correction: Fourth Generation LDPC Error Correction

        Intelligent Health Management: Real time Health Status Monitoring

3. Intelligent management function

          Hot swappable support: Compliant with NVMe hot swappable standards

          Health status monitoring: Telemetry 2.0 telemetry

          Intelligent temperature control: Multi zone temperature sensor

          Remote management: NVMe MI 1.2 management interface

4、 Compatibility information

          Supported Dell EMC Systems:

          PowerMax 2500/8500 Full Flash Array

          PowerEdge MX series modular servers

          Unity XT 680F/880F hybrid storage

          VxRail P-series hyper fusion system

         Software environment support:

         VMware HANA 7.0 U3 and above

         Windows Server 2022

         Red Hat Enterprise Linux 8.5 and above

         SUSE Linux Enterprise Server 15 SP3

5、 Recommended application scenarios

1. Ultra large scale data center

          Hyper converged infrastructure

         Software defined storage platform

         Cloud service provider infrastructure

2. Key business of the enterprise

          Ultra large database system

          Enterprise level data warehouse

          Key business application storage

3. Artificial Intelligence and Big Data

          AI training platform storage

           Machine learning workloads

           Big data analysis platform

4. High performance computing

          Scientific research computation

          Financial modeling analysis

          4K/8K video processing
