Enterprise grade solid state drive 1.92TB U.2 NVMe SSD 118000043-01 005051102 database disk storage expansion

EMC Enterprise NVMe Solid State Drive - Model 118000043-01 Product Detailed Description

1. Product Overview

      The EMC 118000043-01 (Part Number: 005051102) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. Utilizing advanced 3D TLC NAND flash technology, this product is based on the PCIe interface and NVMe protocol, delivering exceptional performance and reliability for enterprise workloads, making it suitable for various data center application scenarios.

II. Detailed Technical Specifications

       Parameter Category  Detailed Specifications

       Basic Information

        EMC Part Number 118000043-01

        Replacement Part Number 005051102

        Flash memory type: 3D TLC NAND

        Interface Protocol: NVMe over PCIe

        Physical dimensions: 2.5-inch U.2

        Capacity information

         Nominal Capacity 1.92TB

          Available user capacity ≈1.75TB

          Performance parameters

          Sequential read speed: 3,200 MB/s

          Sequential write speed: 1,800 MB/s

          4K Random Read: 600,000 IOPS

          4K Random Write 150,000 IOPS

          Read and Write Latency

          Read <85μs, Write <15μs

          Reliability parameters

          Durability Level 3 DWPD

         Service life 10.5 PBW

         Mean Time Between Failures: 2,000,000 hours

         Warranty Policy: 5-Year Limited Warranty

III. Core Technologies and Features

1. High-performance architecture

         PCIe 3.0 x4 interface

         NVMe Optimized Protocol Stack

         High-performance flash memory controller

         Support for multiple namespaces

2. Enterprise-level Reliability

         Power Failure Protection Mechanism: Data Integrity Assurance

          End-to-end Data Protection: Comprehensive Verification Mechanism

          Advanced Error Correction: LDPC Error Correction Technology

          Smart Wear Leveling: Extend Service Life

3. Smart Management Function

          Hot-swapping support: Online maintenance capability

          Health Status Monitoring: S.M.A.R.T. Attributes

          Temperature Management: Dynamic Temperature Control Adjustment

          Remote Management: Standard Management Interface

4、 Compatibility information

         Supported Dell EMC Systems:

          Unity series storage array

          PowerEdge series servers

          VxRail hyper fusion system

          PowerMax All Flash Array

          Operating system support:

           VMware HANA 6.7 and above

           Windows Server 2016/2019

           Red Hat Enterprise Linux 7/8

           SUSE Linux Enterprise Server 12/15

5、 Recommended application scenarios

1. General enterprise workloads

         Virtualization platform storage

          Medium sized database applications

          File sharing service

2. Cloud infrastructure

         Virtual machine image storage

          Container persistent storage

          Development and testing environment

3. Commercial applications

          Email server storage

          Web application storage

          Collaborative platform storage
